Customized Stable Long Span Steel Structure Building Industrial
Warehouse With Insulation CE/ISO
Product Description:
Steel structure building warehouse is a new type of light steel
structure building system formed from a main steel framework
comprised of H section, Z section and U section steel components,
the roof and walls utilizing a variety of panels and other
components such as windows, doors, and cranes.
Steel structures are mainly used for construction workshop,
warehouse, apartment, garage industrial building, agriculture
building, sport stadium, show hall, steel hangar and other
functional steel buildings.
Steel structure production process:
1. Production of main steel component
2. Production ofsmall piece
3. Assembling, submerged arc welding, straightening of section
steel
4. All component numbers
5. Cut the marked section steel
6. Assemble
7. Secondary welding
8. Shot blasting and rust removal
9. Spray paint
10. Composite board veneer production
11. C section steel production
12. Accessories production
Customization:
| List of warehouse materials: |
| The basic components of light steel structure | 1. Main rigid frame: composed of columns and beams;If there is a crane, a crane girder
is also included.
A.common materials: Q235, Q355;
B. Common cross-sectional forms of beams and columns: H-shaped
steel, trusses (beams are mostly used), lattice columns;
C. Common structural forms: portal rigid frame, frame structure; |
2. Support system: including tie rods, horizontal supports, inter-column supports, and
corner supports.
A. Tie rods are usually used: steel pipes, rectangular
pipes;H-beam, channel steel, C-beam, angle iron and so on can also
be used;
B. The inter-column support is usually used: round steel, steel
pipe, angle iron;H-beam, channel steel, I-beam, etc. can also be
used;
C. Angle braces are usually used: angle iron; |
3. Enclosure system: including purlins, purlins rods, roof panels, wall panels, doors,
windows, lighting panels, and gas floors.
A. Purlin: mainly used, C-shaped steel and Z-shaped steel are
cold-formed with hot-drawn steel plate and hot-rolled galvanized
steel plate.
B. Wall and roof color plates: mainly using high-strength,
cold-rolled color steel plates, galvanized or aluminum-zinc color
steel plates, stainless steel plates, aluminum alloy plates, and
titanium alloy plates.Commonly used in China is galvanized or
aluminum-zinc color steel plate. |
| Material classification | 1. According to the composition of the material: ordinary carbon steel (Q235) and ordinary low-alloy steel (Q355,
Q390, Q420);Ordinary low-alloy steel is the addition of one or
several alloying elements on the basis of ordinary carbon steel.
2. According to the intensity: Q235, Q355, Q390, Q420;Among them, Q235 and Q355 are commonly used
materials. |
| Basic data for the design(depand on the project need) | 1. Dead load: must be provided |
| 2. Live load: must be provided |
| 3. Wind load: must be provided |
| 4. Snow load: required in areas with snow |
| 5. Ash load: it needs to be provided in dusty places (such as
deserts and cement plants) |
| 6. Crane load: lifting weight, number of cranes. |
| 7. Seismic load: must be provided |
Support and Services:
A. If you have the drawings
We can provide you the full service of production, shipment and
Installation guide, which is high quality and low cost.Because we
own all kinds of technical facilities, complete test instruments
and advanced production processes.
B. No drawings
Our excellent design team will freely design the steel structure
buildings for you.If you give us the following information, we will
give you an satisfactory drawing.
1. Dimension:Length, width, ridge height, eave height, etc.
2. Doors and Windows:Dimension, quantity, installation position.
3. Local Climate:Wind load, snow load, roof load, Seismic load
4. Insulation materials:Insulated Sandwich panel or Single Steel
Sheet
5. Crane beam:If you need it, it will be very helpful that you tell
us its technological parameters.
6. Usage:If you tell us the application of light steel structure
warehouse, we can exactly design the drawings or match suitable
materials for you.
7. Other requirements:Such as fire proofing, transparent roof,
etc.Please kindly inform us, too.
Packing and Shipping:
Product Packaging:
- All steel structure components are packed in bundles and secured
with steel straps.
- Wall and roof panels are packed in pallets and covered with plastic
film.
- Small components and accessories are packed in boxes and labeled
accordingly.
Shipping:
- The steel structure warehouse will be shipped in containers or
shipped in bulk depending on the quantity and destination.
- Shipping costs will be calculated based on the volume, weight, and
destination of the product.
- The estimated delivery time will be provided upon confirmation of
the order and shipping details.
FAQ:
Q:Are you manufacturer or trading company?
A:We are manufacture factory, located in Qingdao city, near to
Qingdao port. And we have total 3 workshops from steel structure to
wall and roof sheet.
Q: How about your quality control?
A: We have got certificate ISO & CE. Products processing through
cutting, bending, welding, shot blasting, ultrasonic testing,
packing, storing, loading to ensure no quality defects.
Q: Is third party inspection available?
A: SGS, BV, TUV, etc. are available, it is according to client
requirement.
Q: How about your delivery time?
A: Generally within 30-45 days, it is according to order quantity,
partial shipment is allowed for big order.
Q: What about the installation?
A: We'll provide the detailed installation drawing, supervisors
guiding installation is available. We can do turnkey job for some
kind of projects.
Q: How to ensure the product you supply is what we want exactly?
A: Sales and engineer team will provide you the suitable solution
according to your requirements before placing order. Proposal
drawing, Shop drawing, 3D drawing, Materials photos, Finished
projects photos are available, which will help you understand the
solution we provided deeply.
