Gable Frame Metal Construction Prefabricated Industrial Steel
Structure Factory Building
Product Description:
Our steel structure building is perfect for industrial, commercial,
or residential use, making it a versatile option for a variety of
needs. Plus, it comes in a variety of customized colors to match
your specific preferences and needs.
Product advantage:
1.Provide you the building design drawing for free.
2.Fast and flexible installation,safe,heat insulating,sound
insulating,water proof,fire proof.
3.High price-performance ratio:convenient installation greatly
reduce the project duration and the cost.
4.Durable:easy project maintenance,can be used more than 50 years.
5.Perfect design:the perfect design completely avoid the seepage
and leakage while complying with the national fire proof level.
6.Bearing capacity:can resist the strong wind and earth quake
impact and bear the big snow load.
Design ability advantage: By using the AutoCAD,PKPM,MTS,3D3S,Tarch,Revit,Tekla
structure,(Xsteel) and other software,we can design complicated
industrial workplant,logistic storage,fowls house,shops and
market,star hotel,office building,dormitory for school,stadium,high
speed railway station,air port and so on.
| Item | Material | Description and surface process |
| Main steel frame | Column and Beam | Q235 or Q355 | H section steel with two coats of mid-gray paint |
| Purlin | Q235 or Q355 | Galvanized C or Z type steel |
| Connecting Pieces | Tie tube | Q235 | Circular Tube with two coats of mid-gray paint |
| Knee-Bracing | Q235 | L50*4 Galvanized angle steel |
| Strutting piece | Q235 | φ12*2.5 Galvanized Circular Tube |
| Column Bracing | Q235 | Circular Tube with two coats of mid-gray paint |
| Horizontal Bracing | Q235 | Circular Tube with two coats of mid-gray paint |
| Casing | Q235 | φ30*2.5 Galvanized Circular Tube |
| Door and Window | Item | Description |
| Door | Roller shutter door or Sliding door |
| Window | PVC Window or aluminum alloy window |
| Other parts | Ventilating device | Fan,Ventilation window |
| Bolt | Foundation bolt,High strengthen bolt, Normal bolts |
| Skylight | Yx-840 Glass Fiber Reinforced Plastics |
| Out/Inner ridge tile | 0.50mm Color sheet |
| Crane beam | Q235 or Q345 H section steel with two coats of mid-gray paint |
| Panel Material parts | (1). External Wall panel: (below is selectable) |
| 1) 50mm, 75mm or 100mm thickness EPS sandwich panel |
| 2) 50mm, 75mm or 100mm thickness glass wool sandwich panel |
| 3) 50mm, 75mm or 100mm thickness Rockwool sandwich panel |
| 4) 50- 250mm thickness PU sandwich panel |
| 3) 900# Corrugated Galvanized Steel sheet with different Color |
| 4) Kinds of PVC wall panel. |
| (2). Internal Wall panel: (below is selectable) |
| 1)50mm, 75mm or 100mm thickness EPS sandwich panel |
| 2) 50mm, 75mm or 100mm thickness glass wool sandwich panel |
| 3) 50mm, 75mm or 100mm thickness Rockwool sandwich panel |
| (3). Roofing panel: (below is selectable) |
| 1)50mm, 75mm or 100mm thickness EPS sandwich panel |
| 2) 50mm, 75mm or 100mm thickness glass wool sandwich panel |
| 3) 50mm, 75mm or 100mm thickness Rockwool sandwich panel |
| 3)Corrugated Steel Sheet, an insulating layer if need. |
| 4)Corrugated PVC roof panel. |
| (4). Skylight: 820# Glass Fiber Reinforced Plastics (FRP) |
Applications:
Our Steel Structure Building is suitable for a variety of occasions
and scenarios. It is perfect for industrial steel construction,
such as factories, workshops, warehouses, and storage facilities.
Our steel structure building can also be used for construction
structural steel, such as office buildings, commercial buildings,
and residential buildings. It is designed to be durable,
long-lasting, and cost-efficient.
The roof and wall of our Steel Structure Building are made of steel
sheet or sandwich panel with a thickness of 5-50mm. It comes with
various accessories such as flashing, skylight, fans, gutter, etc.
Our product is certified by SGS/CE/ISO, and can be customized in
color to meet your specific needs.
Support and Services:
Our Steel Structure Building product comes with comprehensive
technical support and services to ensure that you have a smooth
experience from start to finish. Our technical support team is
available to answer any questions you may have throughout the
installation and use of our product.
We offer a range of services to help you get the most out of your
Steel Structure Building, including:
- Custom design and engineering services to ensure that your building
meets all local regulations and requirements
- Installation services, including on-site supervision and project
management
- Training and education services to help you and your team make the
most of your building
We are committed to providing the highest level of support and
services to our customers. If you have any questions or concerns,
please do not hesitate to contact us.
FAQ:
Q:Are you manufacturer or trading company?
A:We are manufacture factory, located in Qingdao city, near to
Qingdao port. And we have total 3 workshops from steel structure to
wall and roof sheet.
Q: How about your quality control?
A: We have got certificate ISO & CE. Products processing through
cutting, bending, welding, shot blasting, ultrasonic testing,
packing, storing, loading to ensure no quality defects.
Q: Is third party inspection available?
A: SGS, BV, TUV, etc. are available, it is according to client
requirement.
Q: How about your delivery time?
A: Generally within 30-45 days, it is according to order quantity,
partial shipment is allowed for big order.
Q: What about the installation?
A: We'll provide the detailed installation drawing, supervisors
guiding installation is available. We can do turnkey job for some
kind of projects.
Q: How to ensure the product you supply is what we want exactly?
A: Sales and engineer team will provide you the suitable solution
according to your requirements before placing order. Proposal
drawing, Shop drawing, 3D drawing, Materials photos, Finished
projects photos are available, which will help you understand the
solution we provided deeply.
