residential helical screw post anchor
Product Introduction
Helical anchors are used for new construction and to support
existing structures. They are designed for applications in
expansive soils, high water tables, fill areas, and other areas
where unstable soils require a deep foundation. In compression they
are used as footers and in tension they may be used tosupport
retaining or foundation walls. Helical piers are round or square,
tubular or bar steel shafts with round helix plates welded to them.
Product Features
Product Specifications
Specifications | |||
Size | Lead Length (ft) | Helix Size (inch) | Extension Length(ft) |
1-1/2" | 3ft/5ft/7ft | 8/10/12/14 | 3ft/5ft/7ft/10ft |
1-3/4" | 3ft/5ft/7ft | 8/10/12/14 | 3ft/5ft/7ft/10ft |
2" | 3ft/5ft/7ft/10ft | 8/10/12/15 | 3ft/5ft/7ft/10ft |
Product Advantages
1.Bar Material: 40Cr or 45# steel, round corner 5mm radiu
2.Helix Plate material conforms to ASTM A36 hot rolled plate
3.helices thickness are available in 3/8" and 1/2" inch
4.All helix leading edges sharpened and rock cut and 45 degrees.
5.Corrosion protection to conform to ASTM A153 standard for hot
dipped zinc coating
6.A better conventional solid steel extra high strength helical
screw pile
7.Welded coupling for greater strength. Eliminates shaft heat
damage caused by upset coupling process
If you are interested in our helical anchors/screw piles, please
don't hesitate to contact us, we will offer the best price, highest
quality, excellent service for you.
Round Shaft Helical Pile | |||||||
Shaft Size OD in (mm) | Wall Thickness in (mm) | Metal Area in² (cm²) | Perimeter in (cm) | Helix Size in | Helix Thickness in | Lead Length ft | Extension Length ft |
2.875 (73) | 0.203(5.2) | 1.7 (11.0) | 9.0 (22.9) | 8/10/12/14 | 3/8 or 1/2 | 3/5/7 | 3/5/7/10 |
2.875 (73) | 0.276(7.0) | 2.3 (14.8) | 9.0 (22.9) | 8/10/12/14 | 3/8 or 1/2 | 3/5/7 | 3/5/7/10 |
3.5 (89) | 0.300 (7.6) | 3.0 (19.5) | 11.0(27.9) | 8/10/12/14 | 3/8 or 1/2 | 3/5/7 | 3/5/7/10 |
4.5 (114) | 0.337(8.6) | 4.4 (28.4) | 14.1(35.9) | 8/10/12/14 | 3/8 or 1/2 | 3/5/7/10 | 3/5/7/10 |
6.625 (168) | 0.28 (7) | 5.58 (36.0) | 20.8(52.8) | 8/10/12/14 | 3/8 or 1/2 | 3/5/7/10 | 3/5/7/10 |
8.625 (219) | 0.25(6) | 6.58 (42.5) | 27.1(68.8) | 8/10/12/14 | 3/8 or 1/2 | 3/5/7/10 | 3/5/7/10 |
All above sizes, steel grade are customizable. |
![]() |
