Insulated Metal Portable Modular Prefabricated Helicopter Aircraft
Steel Structure Hangar
Product Description:
A steel building from KXD Steel is the most reliable solution for a
private aircraft hangar. Protecting your prized asset is of the
utmost importance, and steel construction offers the strength and
design flexibility that ensures the safety and proper maintenance
of your aircraft. Our steel structures feature clear span framing,
allowing for column-free interiors that maximize space. Every steel
building from KXD Steel is designed according to use.
Technical Parameters:
| The main options of the componets are as the following: |
| Main Structure | Column | Q355B Welded H column |
| Rafter, Beam | Q355B Welded H column |
| Surface processing options | 1. Epoxy zinc-rich primer + epoxy mica termediate paint |
| 2. Hot dip galvanization |
| Sub Structure | Purlin | Q235B, C section steel, galvanization 80-275g/m2 |
| Angle brace | Q235B, L- steel |
| Cross bracing | Q235B round bar, L-steel |
| Tie bar | Q235B, round pipe |
| Batter brace | Q235B, round bar |
| Roof System | Roof panel options | 1. Insulated sandwich panel, PU, rock wool, glass fiber, EPS. Both
sides are steel sheet. Thickness of roof panel 50mm/75mm/100mm,
thickness of steel sheet 0.4mm/0.5mm/0.6mm |
| 2. Steel plate, thickness 0.4mm-0.6mm |
| Gutter options | 1. Galvanized steel gutter, thickness 2.0mm/2.5mm, 3.0mm |
| 2. Painted, Pre-finished steel gutter, thickness 0.4mm/0.5mm/0.6mm |
| Down spout | PVC pipe |
| Steel flashing and cover | Steel sheet for roof ridge cap, gable wall end cover and corner
cover |
| Options | Roof skylight 1.8mm PVC sheet and stainless steel ventilator |
| Wall System | Wall panel options | 1. Insulated sandwich panel, PU, rock wool, glass fiber, EPS. Two
sides is steel sheet. Thickness of wall panel 50mm/75mm/100mm,
thickness of steel sheet 0.4mm/0.5mm/0.6mm |
| 2. Steel plate, thickness 0.4mm/0.5mm |
| 3. Brick wall (provided by client) |
| Door | 1. Roller door for truck, size customized |
| 2. Sliding door for truck, size customized |
| 3. Access door, steel door, glass door etc. |
| Window | PVC or Aluminum frame, Fixed, swing, sliding, louver etc, size
customized |
| Steel flashing and cover | Steel sheet end cover and corner cover |
| Accessories and fasteners | | Anchor bolts, chemical bolts, high strength bolts, ordinary bolts,
self-tapping screws, rivet etc. |
Applications:
While many airplane hangar manufacturers offer one or two designs
with stock options, we can help you customize your hangar design
just how you want it. Your new steel hangar kit can be designed to
accommodate any type of aircraft, thanks to our wide range of door
options, as well as adapted to incorporate living quarters or be
built as a part of another building type – even an entire metal
home.
Plus, because our metal building kits are incredibly easy to
modify, you can always expand your square footage down the line if
your fleet of aircraft ever increases, or if you want your steel
airplane hangar to play double-duty.
Support and Services:
Our Steel Structure Hangar product comes with comprehensive
technical support and services to ensure that you have a smooth
experience installing and using our product. Our team of experts
are available to assist with any questions or concerns you may have
regarding the product's specifications, installation, maintenance,
or troubleshooting. Our technical support and services include:
- Consultation and advice on product specifications and requirements
- Installation support and guidance
- Regular maintenance services
We are committed to providing the highest level of support and
services to our customers to ensure that you get the most out of
your Steel Structure Hangar product.
Packing and Shipping:
Product Packaging:
- All steel components are wrapped in protective materials to prevent
damage during transportation and storage.
- Small components are organized into boxes and labeled for easy
identification.
- The hangar panels are stacked and secured onto pallets for safe and
efficient shipping.
- All components are loaded onto a flatbed truck or container for
transportation.
Shipping:
- Shipping is available worldwide.
- Shipping costs are calculated based on the destination and weight
of the product.
- Delivery times vary depending on the destination and shipping
method chosen.
- We work with trusted shipping partners to ensure timely and safe
delivery of our products.
FAQ:
Q:Are you manufacturer or trading company?
A:We are manufacture factory, located in Qingdao city, near to
Qingdao port. And we have total 3 workshops from steel structure to
wall and roof sheet.
Q: How about your quality control?
A: We have got certificate ISO & CE. Products processing through
cutting, bending, welding, shot blasting, ultrasonic testing,
packing, storing, loading to ensure no quality defects.
Q: Is third party inspection available?
A: SGS, BV, TUV, etc. are available, it is according to client
requirement.
Q: How about your delivery time?
A: Generally within 30-45 days, it is according to order quantity,
partial shipment is allowed for big order.
Q: What about the installation?
A: We'll provide the detailed installation drawing, supervisors
guiding installation is available. We can do turnkey job for some
kind of projects.
Q: How to ensure the product you supply is what we want exactly?
A: Sales and engineer team will provide you the suitable solution
according to your requirements before placing order. Proposal
drawing, Shop drawing, 3D drawing, Materials photos, Finished
projects photos are available, which will help you understand the
solution we provided deeply.
