Product Description:
The main frame of our Steel Structure Workshop is made from light
steel Q345 Q235, which provides excellent strength and durability.
This makes it the ideal choice for building facilities and
construction materials that require a high level of stability and
support.
The Snow Load for our workshop ranges from 0.5-1.0KN/m², which
makes it suitable for use in areas with heavy snowfall. The roof
and walls are made from high-quality materials such as EPS, Glass
Wool, Rock Wool, and PU. These materials are known for their
excellent insulation properties, which help to keep the workshop
warm in winter and cool in summer.
Steel workshops are versatile, providing an extensive range of
uses. They are easy to assemble and disassemble, cost-effective
when compared to other construction materials, and are perfect for
any facility that requires a strong, durable building. From large
supermarkets to clothing factories and bottled water plants, steel
workshops have become an increasingly popular choice.
Technical Parameters:
| Application: | steel structure, China steel structure , steel structure China
,steel warehouse, steel structure building, steel structure
warehouse, steel workshop, steel structure workshop,hangar, sport
hall, steel hall,shopping mall, cow shed, poultry house ,etc |
| Clear span:(width) | 6~50m without middle column |
| Height | 2~20m |
| Length | as your requirement |
| Material Grade | Q345(S355JR)or Q235(S235JR) steel or as request |
| Column & Rafter | Welded or Hot rolled H beam |
| Tie beam | round pipe or square tube or as request |
| X brace | round steel bar, angle steel or as request |
| Purlin | C purlin, Z purlin,thickness 2.0mm,2.2mm,2.5mm,3.0mm |
| sag rod | steel round bar, angle, C purlin etc |
| Wall & Roof coverage | single corrugated steel sheet (0.12~1.2mm) |
| EPS, Rock wool, glass fiber ,PU core foam sandwich Panel |
| (Thickness:50mm,75mm,100mm,150mm,200mm) |
| Gate | Electric roller shutter door/Sliding door |
| Exit Door | Plastic steel/Aluminum alloy swing door/ steel swing door |
| Window | Plastic steel or Aluminum alloy frame |
| sliding window/ vent/top Hung window |
| Surface | Shot blasting with anti rust paint rich-zinc epoxy paint etc |
| hot dip galvanize |
| Certificate | ISO90001,CE EN1090 EXC2 ,IWE etc |
| Quality Control | The third party ,SGS, QIMA, BV all accept |
| Crane | 5MT, 10MT, 15MT, etc. |
| Other accessories | gutter, flashing trimming cover, down spout, ventilation fitting, |
| skylight belt, bolt, anchor bolt, self tapping screw etc |
| Package | main steel frame etc load in 40'OT,roof and wall panel load in
40'HQ! |
Applications:
Versatility: A steel workshop can be designed to meet a wide range of
industrial requirements. Whether it's a warehousing, manufacturing,
or processing facility, a steel workshop can be tailored to any
specific needs.
Ease of installation: Compared to traditional build-ups, the installation process for a
steel workshop is relatively easy and quick. This means your
facility can be up and running at a faster rate than with other
construction materials.
Cost-effectiveness: A steel workshop is one of the most cost-effective building
options available. The materials are affordable, and the
construction process requires fewer workers and less time, reducing
labor costs. Plus, steel is a low-maintenance material, which can
save you a significant amount of money in upkeep costs.
Durability: Durability is a crucial factor when it comes to industrial
buildings. A steel workshop is durable enough to withstand the
heavy usage and environmental factors that industrial facilities
face daily. Plus, steel is known for its strength and resistance to
damage from weather and natural disasters.
Support and Services:
The Steel Structure Workshop product comes with comprehensive
technical support and services to ensure optimal performance and
longevity of the structure. Our team of experts is available to
offer assistance with installation, maintenance, and repair of the
workshop.
| Drawings & Quotation Information: |
| 1) Customized design is welcomed. |
| 2) Could you tell me your steel structure project? |
| Basic design requirements and design Load |
| 1. Project site location: |
| 2.Overall dimension(length*width*eave height in meters): |
| 3. Mezzanine or not?How many kgs of load per square meter on
mezzanine? |
| 4. Single-layer steel sheet wall or sandwich panel wall: |
| 5. Snow load if applicable: |
| 6. Wind speed/load: |
| 7. Interior column allowed or not: |
| 8. Overhead crane needed or not, capacity?: |
| 9. Any other particular requirements?: |
| Building Purpose: we will recommend the best design for the purpose
of the building |
| A.Warehouse/Storage |
| B.Factory |
| C.Agriculture Barn |
| E.Repair/Mechanic Shop |
| F.Office Space |
| G.Medical Warehouse |
| H.Animal Farm (please confirm what kind of animal) |
Packing and Shipping:
Product Packaging:
- All steel components are packed in bundles and secured with steel
straps.
- All panels and accessories are packed in wooden boxes.
- All packages are labeled with product information and shipping
marks.
- Packaging is designed to protect the product during transportation.
Shipping:
- Shipping can be arranged by sea or by land.
- Shipping costs will vary depending on the destination and the
quantity of the product.
- Delivery times will depend on the shipping method and the distance
to the destination.
- Customers will be notified of the shipping details once the product
is ready to be shipped.
FAQ:
Q:Are you manufacturer or trading company?
A:We are manufacture factory, located in Qingdao city, near to
Qingdao port. And we have total 3 workshops from steel structure to
wall and roof sheet.
Q: How about your quality control?
A: We have got certificate ISO & CE. Products processing through
cutting, bending, welding, shot blasting, ultrasonic testing,
packing, storing, loading to ensure no quality defects.
Q: Is third party inspection available?
A: SGS, BV, TUV, etc. are available, it is according to client
requirement.
Q: How about your delivery time?
A: Generally within 30-45 days, it is according to order quantity,
partial shipment is allowed for big order.
Q: What about the installation?
A: We'll provide the detailed installation drawing, supervisors
guiding installation is available. We can do turnkey job for some
kind of projects.
Q: How to ensure the product you supply is what we want exactly?
A: Sales and engineer team will provide you the suitable solution
according to your requirements before placing order. Proposal
drawing, Shop drawing, 3D drawing, Materials photos, Finished
projects photos are available, which will help you understand the
solution we provided deeply.
